Giant 2024 Trance 29 1
TURN UP THE HEAT ON TECHNICAL TRAILS. WITH 120MM OF SMOOTH MAESTRO REAR SUSPENSION AND ADJUSTABLE GEOMETRY, THIS NIMBLE 29ER ADAPTS TO THE TERRAIN WITH MORE CONFIDENCE AND CONTROL.
Adjustable frame geometry
Flip chip feature lets you adjust the head tube and seat tube angles, as well as bottom bracket height, to fine tune handling for varying trail conditions and individual riding style.
29er confidence and control
Larger 29-inch diameter wheels optimized to roll over rough terrain with balance and stability, giving you the momentum to tackle technical climbs and the confidence to fly on fast, rugged singletrack descents.
Progressive trail design
Lightweight, strong and durable ALUXX SL aluminum frameset features a longer reach and steeper seat tube angle for aggressive trail riding and improved climbing capabilities.
Specifications
Giant 2024 Trance 29 1
Frame
Colour: Panther/Pyrirte BrownFrame: Advanced-Grade Composite front and rear triangles, 120mm Maestro suspension, flip chip, UDH hanger, 12x148mm thru-axle, 55mm Chainline
Fork: Fox 34 Float Performance, 130mm, GRIP damper, Boost 15x110 Kabolt, 44mm offset, custom tuned for Giant
Shock: Fox Float DPS Performance, custom tuned for Giant
Drivetrain
Crankset: Shimano SLX, 30t M:170mm, L:170mm, XL:170mm, 55mm chainlinePedals:
Chain: KMC X-12
Bottom Bracket: Shimano, press fit
Rear Derailleur: Shimano SLX RD-M7100 Shadow
Front Derailleur: NA
Derailleur Shifter: Shimano SLX SL-M7100, 1x12
Freewheel/Cassette: Shimano SLX, 10x51
Wheels
Tyres: [F] Maxxis Minion DHF 29x2.5 WT, 3C MaxxTerra, EXO, TR [R] Maxxis Aggressor 29x2.5, EXO, TR, tubelessWheels/Rims: Giant AM 29, tubeless ready sleeve-joint rim, 30mm inner width
Hubs: [F] Giant MTB alloy, 6-bolt [R] Giant MTB alloy, 3-pawl driver, 6-bolt
Braking System
Brakes: Shimano BR-MT520, hydraulic, Shimano RT-56 rotors [F]180mm, [R]180mmBrake Levers: Shimano BL-MT501
Other
Handlebar: Giant Contact TR35, alloy, 35mmStem: Giant Contact SL 35 M:40mm, L:50mm, XL:50mm
Saddle: Giant Romero
Seat Post: TranzX travel-adjustable dropper, remote M: 140-170mm travel / 30.9 x 499mm L: 170-200mm travel / 30.9 x 525mm XL: 170-200mm travel / 30.9 x 525mm
Geometry
Giant 2024 Trance 29 1
-
- S
- 163 cm 172 cm
-
- M
- 171 cm 180 cm
-
- L
- 179 cm 188 cm
-
- XL
- 187 cm 198 cm
| S | M | L | XL | ||
| A | SEAT TUBE LENGTH (mm) | 420 | 430 | 465 | 496 |
| B | SEAT TUBE ANGLE | 77.2° | 76.3° | 76.3° | 76.3° |
| C | TOP TUBE LENGTH (mm) | 561 | 599 | 626 | 663 |
| D | HEAD TUBE LENGTH (mm) | 100 | 110 | 120 | 130 |
| E | HEAD TUBE ANGLE | 65.4° | 65.5° | 65.5° | 65.5° |
| F | FORK RAKE (mm) | 44 | 44 | 44 | 44 |
| G | TRAIL (mm) | 126.0 | 126.0 | 126.0 | 126.0 |
| H | WHEELBASE (mm) | 1166 | 1195 | 1124 | 1263 |
| I | CHAIN STAY LENGTH (mm) | 439 | 439 | 439 | 439 |
| J | BOTTOM BRACKET DROP (mm) | 45 | 45 | 45 | 45 |
| K | STACK (mm) | 610 | 619 | 628 | 637 |
| L | REACH (mm) | 422 | 447 | 472 | 507 |
| M | STAND OVER HEIGHT (mm) | 730 | 725 | 749 | 771 |
| N | HANDLEBAR WIDTH (mm) | 780 | 780 | 780 | 780 |
| O | STEM LENGTH (mm) | 40 | 40 | 50 | 50 |
| P | CRANK LENGTH (mm) | 165 | 170 | 170 | 170 |
| Q | WHEEL SIZE | [F] 29" [R] 29" | [F] 29" [R] 29" | [F] 29" [R] 29" | [F] 29" [R] 29" |
